Casting C377G

Ultimate power potential!

C377G drives all eight rollers with independent motors. Since all four pairs of rollers open on both sides, the path line of the wire is always constant regardless of the thickness of the wire. By opening and closing the roller in the vertical / horizontal direction, damage to the processed wire is minimized, and stable cutting and stripping are always possible.

It can be easily moved and installed with casters.

Processing capacity

Processing conditions:

▪Front/Rear strip length 10mm

▪Core diameter 10mm

Total Length	Speed 9	Speed 7
290mm	740 pcs/hour	600 pcs/hour
500mm	700 pcs/hour	570 pcs/hour
1,000mm	630 pcs/hour	510 pcs/hour
2,000mm	510 pcs/hour	420 pcs/hour
3,000mm	430 pcs/hour	350 pcs/hour
5,000mm	330 pcs/hour	270 pcs/hour

Specification

Model	C377G
Stripping Length	Front：0.1mm～114mm / Rear：0.1mm～99mm
Cutting Length	0.1mm～99,999mm
Cutting Tolerance	± (0.1+0.0005×L) mm
Wire Size	100sq～AWG#16 (1.25sq)　*Depends on the wire type
Wire Diameter	Maxφ20mm　*Depends on the wire type
Wire Type	Battery cable, WL1, WL2, VSF, IV, KV, Teflon etc.
Power Supply	AC100V～240V　50/60Hz
Air Supply	8Nl/min　0.5MPa
Drive Supply	Stepping motor / Air cylinder
Dimension	710×470×1,400mm
Weight	156kg

Downloads

【NEW PRICE】C377G Consumable Part List *since July 2023～

C377G Catalog

C377G Specification
