Casting C376A
The condensed tough performance
C376A can be widely used in a wide variety of industries since it corresponds to the round cable up to φ17mm maximum diameter.
Processing capacity
Processing conditions:
▪Front/Rear strip length 3mm
▪Core diameter 0.75mm
▪Program A200
| Total Length | Processing Capacity |
| 100mm | 1,710 pcs/hour |
| 200mm |
1,580 pcs/hour |
| 300mm | 1,460 pcs/hour |
| 500mm | 1,260 pcs/hour |
| 1,000mm | 970 pcs/hour |
| 2,000mm | 660 pcs/hour |
| 3,000mm | 500 pcs/hour |
Specification
|
Model |
C376A |
| Cutting Length | 0.1mm～99,999mm |
| Cutting Tolerance | ± (0.1+0.0005×L) mm *L indicates a cutting length |
| Wire Size | 50sq～0.75sq *Depends on the wire type |
| Wire Diameter | Maxφ17mm *Depends on the wire type |
| Wire Type | AV, MLFC, VSF, IV, KV, UL, Teflon etc. |
| Power Supply | AC100V, AC200V～240V 50/60Hz |
| Air Supply | 9Nl/min 0.5MPa |
| Optional Equipment | None |
| Dimension | 540×545×335mm |
| Weight | 52kg |
